ONNX Runtime's Optimization Levels Do Completely Different Things to Different Models
ONNX Runtime has a graph_optimization_level knob with four settings — disable, basic, extended, all — and it defaults to all, which is why nobody ever looks at it. I wanted to look anyway, for the same reason as the threading post: the models I deploy are nothing like the models in vendor benchmarks, and defaults tuned for one can behave strangely on the other. So: my three standing CPU models — the tiny HAR fp32 network (374 KB), its static-int8 sibling (103 KB), and ResNet18 (43 MB) — at every level, with batch-1 latency over 500 runs, node counts of the optimized graph, and session startup cost.
Three models, three entirely different stories
| level | HAR int8 (34 nodes) | ResNet18 fp32 (65 nodes) | HAR fp32 (11 nodes) |
|---|---|---|---|
| disable | 0.089 ms (34 nodes) | 9.95 ms (65 nodes) | 0.066 ms (11) |
| basic | 0.089 ms (34) | 9.93 ms (49) | 0.063 ms (11) |
| extended | 0.042 ms (10) | 9.84 ms (40) | 0.047 ms (8) |
| all | 0.026 ms (12) | 6.37 ms (25) | 0.058 ms (8) |
The int8 column is the dramatic one, and its top row contains the finding I’d frame: an int8 model with graph optimization disabled runs slower than the fp32 model it was quantized from — 0.089 ms against 0.066. Quantized graphs are full of QLinear operators and quantize/dequantize pairs that only pay off once the extended pass fuses them into integer kernels (34 nodes collapse to 10, latency halves); before that pass, quantization is a pessimization. If you ever load a quantized model through a runtime path that lowers the optimization level — some wrappers do, “for compatibility” — you silently get the worst of both worlds: int8 accuracy loss at worse-than-fp32 speed.
ResNet18 tells the opposite story about where speed lives. The basic and extended passes remove twenty-five nodes’ worth of Conv+BN foldings and activation fusions — the optimizations everyone can name — and buy a combined one percent. The jump to all, which on CPU triggers the NCHWc layout transformation (rewriting the whole graph to a cache-friendly blocked memory format), buys 35% in one step. Node count drops from 65 to 25 across the levels, but the correlation between nodes removed and milliseconds saved is essentially zero: sixteen nodes for 0.2%, then fifteen nodes for 3.5 ms. Graph size is bookkeeping; memory layout is money.
The regression that wasn’t
The HAR fp32 column initially handed me a much better headline: all measured 19% slower than extended (0.058 vs 0.047), meaning the default would be actively wrong for tiny models — the layout transformation overhead exceeding its benefit at this scale. Plausible mechanism, satisfying contrarian shape, and I’ve been burned by exactly that combination before, so I re-ran the comparison three times before writing this paragraph. It evaporated: across trials, extended landed at 0.056–0.064 ms and all at 0.054–0.061, fully overlapping. At the 0.05-millisecond scale, run-to-run drift between whole benchmark invocations is larger than the effect I was about to publish; the 500-run median protects against in-run jitter but not against the machine being in a different mood five minutes later. The honest reading of that column is “extended and all are the same, both modestly better than nothing” — and a reminder that a microbenchmark’s precision has to be established before its verdict is quoted.
Two practical footnotes. Optimization runs at session creation and isn’t free — ResNet18’s startup went from 73 ms to 129 ms at level all, which matters only if you cold-start sessions per request (don’t). And you can pay it offline via optimized_model_filepath, but ORT itself warns that graphs serialized above extended contain hardware-specific transforms — an NCHWc-optimized model saved on my desktop shouldn’t ship to a different CPU family. The takeaway is unexciting on purpose: the default is correct, this knob is not a tuning opportunity — it’s a footgun that only fires if something lowers it. But knowing which pass feeds your model is worth the ten minutes: mine told me the int8 deployment lives or dies on operator fusion, while the big fp32 model’s entire speed story is memory layout, and no amount of node-counting would have revealed either.
