channels_last: 1.4x Faster in bf16, 4x Slower in fp16, on the Same GPU
The performance checklist I’ve been working through on this blog — cuDNN and TF32 flags, then autocast — has one classic line left on it:
model = model.to(memory_format=torch.channels_last)
x = x.to(memory_format=torch.channels_last)PyTorch stores image tensors as NCHW by default — all of channel 0’s pixels, then channel 1’s. Tensor cores prefer the interleaved NHWC layout, where each pixel’s channels sit together, and channels_last gives you NHWC without changing the tensor’s logical shape: same indices, different bytes underneath. The docs promise meaningful speedups for convnets with mixed precision on modern GPUs. Having just set up AMP, this was the obvious next test: same ResNet18 training step, same RTX 4080 Super, PyTorch 2.6.0, median of 50 iterations.
This turned out to be the strangest table this series has produced.
The table with a hole in it
Training step (forward + backward + optimizer), with and without channels_last:
| batch | precision | NCHW | channels_last | verdict |
|---|---|---|---|---|
| 32 | fp32 | 17.2 ms | 50.8 ms | 3.0x slower |
| 32 | bf16 | 11.1 ms | 9.1 ms | 1.22x faster |
| 32 | fp16 | 10.9 ms | 40.3 ms | 3.7x slower |
| 128 | fp32 | 77.1 ms | 245.4 ms | 3.2x slower |
| 128 | bf16 | 47.2 ms | 34.8 ms | 1.36x faster |
| 128 | fp16 | 42.5 ms | 172.5 ms | 4.1x slower |
The bf16 row is the documentation coming true: 22–36% faster from one line, on top of everything the previous two posts already banked. Chained together — TF32, autocast, channels_last, all in bf16 — the batch-128 training step went from last week’s 75.8 ms to 34.8 ms, a 2.2x total that cost four lines of code.
The fp32 rows going backwards is at least a known caveat: without tensor-core-friendly kernels to exploit the layout, you pay transposition costs for nothing. The docs quietly assume mixed precision, and now you’ve seen the price of ignoring that assumption — you don’t just fail to gain, you triple your step time.
The fp16 rows are the hole. fp16 with channels_last is the canonical combination — it’s the pairing NVIDIA’s tensor-core guides are written around — and on my stack it trains four times slower than plain NCHW fp16. Not a few percent of noise: 42.5 ms to 172.5 ms.
Localizing it
My first suspicion was the backward pass, since inference-only numbers looked healthy. So I timed forward and backward separately for fp16, batch 32:
| forward | backward | |
|---|---|---|
| NCHW | 3.9 ms | 7.1 ms |
| channels_last | 14.9 ms | 23.2 ms |
Both halves fall off the same cliff — but only when gradients are in play. Under torch.inference_mode(), the identical model and input in fp16 + channels_last was faster than NCHW (2.46 vs. 3.00 ms at batch 32), exactly as advertised. Same tensors, same layout, same GPU; the only difference is whether autograd is recording. That pattern points at cuDNN algorithm selection taking a bad path for NHWC fp16 convolutions in the training graph on this particular stack — benchmark=True was on and fully warmed up, so it’s not the autotuner being cold; whatever kernels are reachable in that configuration are simply slow ones.
I want to be careful about scope here: this is one GPU, one PyTorch build (2.6.0+cu126), one OS, one architecture. I am not claiming fp16 + channels_last is broken in general — bf16 on the same machine behaves perfectly, which is strong evidence the mechanism is a narrow kernel-selection gap rather than anything fundamental. But that’s precisely the kind of gap that never appears in documentation, release notes, or tutorials, and it inverts the standard advice: on this stack, following the canonical recipe would have quadrupled my training time, and the “second choice” dtype is the one that delivers.
Two layout gotchas for the road
While setting up the benchmark I also confirmed the two behaviors that make channels_last a mild footgun even when it’s fast.
First, the format is contagious by design: elementwise math, cat, and most ops preserve channels-last-ness, so one converted input quietly converts everything downstream. That’s how it’s supposed to work — you convert the model and inputs once at the boundary — but it means a stray converted tensor from a cache or a preprocessing step can flip layouts somewhere deep in a pipeline without any visible change in shapes or values.
Second, .view() on a channels-last tensor can simply refuse: RuntimeError: view size is not compatible with input tensor's size and stride. Code that flattens feature maps with x.view(n, -1) — which describes an enormous amount of model code, including some of mine — breaks the moment its input goes NHWC. reshape() or flatten() handle it (at the cost of a copy when needed), but if you adopt channels_last, that error message will eventually find you.
Where this leaves the checklist
For my own training runs the outcome is clean: bf16 + channels_last is now the default — it stacked another 1.2–1.4x on top of autocast and it dodges both the fp16 scaler machinery and whatever kernel pothole fp16 NHWC hits here. channels_last in fp32 stays off, always. And fp16 + channels_last, the combination every tensor-core guide leads with, goes into the same bin as cudnn.benchmark from two posts ago: advice that was presumably true on the hardware and software it was written on, transplanted forward by repetition rather than by anyone re-checking it. Four flags into this series, the pattern is consistent enough that I’d state it as a rule: the older and more canonical the performance advice, the more it needs a stopwatch held to it on your actual stack before it touches a real training run.
